HFFS Horizonal
Form & Fill Seal Machine
Automatic roll film pouch packing machine is an efficient and intelligent packaging equipment, suitable for all kinds of granules, powders, liquids and other raw materials. This equipment adopts automatic control system, with the roll film (such as PE, PP, PET, aluminum foil, etc.), to achieve automatically bag making, filling, sealing, cutting and other processes. Meanwhile, for different bag types, our engineers will modify the mechanical design on this basic model to realize the packaging of many kinds of shaped bags.
Why Choose Us
- 1. UV sterilization extends the shelf life of the product
- 2. CNC made Powerless roller, low resistance and high concentricity
- 3. Adjustable temperature, can adapt to a variety of packaging materials
- 4. Millimeter-level deflector to prevent the package from running off and the bag from showing white
- 5. High-precision non-powered inversion roller, low resistance, smoother film walking
- 6. Longer life, up to 10 million times or more. Punching out products without burr and high precision of contour size
| Technical Data | 110N/110NZ | 180N | 180ND | 210N | 210ND | 240N | 240ND |
|---|---|---|---|---|---|---|---|
|
Pouch Size |
W 40-110mm
L 80-160mm |
W 70-180mm
L 130-225mm |
W 60-90mm
L 90-180mm |
W 70-210mm
L 130-225mm |
W 70-105mm
L 130-300mm |
W 75-240mm
L 85-225mm |
W 70-120mm
L 120-300mm |
|
Filling Volume |
110mL |
400mL |
100mL |
750mL |
120mL |
1000mL |
150mL |
|
Packaging Speed |
≤60 |
≤60 |
≤100 |
≤55 |
≤120 |
≤50 |
≤120 |
|
Dimension |
2650*900*1460mm |
3500*970*1450mm |
3500*970*1450mm |
4000*970*1450mm |
4000*970*1450mm |
4500*970*1460mm |
5200*970*1460mm |
|
Weight |
1300kg |
1800kg |
1800kg |
2000kg |
2000kg |
2100kg |
2100kg |
|
Power |
3.5kW |
5kW |
5.5kW |
5.5kW |
5.5kW |
5.5kW |
5.5kW |
|
Air Consumption |
200L/min |
200L/min |
200L/min |
300L/min |
300L/min |
300L/min |
300L/min |
Why Choose Us
- 1. UV sterilization extends the shelf life of the product
- 2. CNC made Powerless roller, low resistance and high concentricity
- 3. Adjustable temperature, can adapt to a variety of packaging materials
- 4. Millimeter-level deflector to prevent the package from running off and the bag from showing white
- 5. High-precision non-powered inversion roller, low resistance, smoother film walking
- 6. Longer life, up to 10 million times or more. Punching out products without burr and high precision of contour size
| Technical Data | 110N/110NZ | 180N | 180ND | 210N | 210ND | 240N | 240ND |
|---|---|---|---|---|---|---|---|
|
Pouch Size |
W 40-110mm
L 80-160mm |
W 70-180mm
L 130-225mm |
W 60-90mm
L 90-180mm |
W 70-210mm
L 130-225mm |
W 70-105mm
L 130-300mm |
W 75-240mm
L 85-225mm |
W 70-120mm
L 120-300mm |
|
Filling Volume |
110mL |
400mL |
100mL |
750mL |
120mL |
1000mL |
150mL |
|
Packaging Speed |
≤60 |
≤60 |
≤100 |
≤55 |
≤120 |
≤50 |
≤120 |
|
Dimension |
2650*900*1460mm |
3500*970*1450mm |
3500*970*1450mm |
4000*970*1450mm |
4000*970*1450mm |
4500*970*1460mm |
5200*970*1460mm |
|
Weight |
1300kg |
1800kg |
1800kg |
2000kg |
2000kg |
2100kg |
2100kg |
|
Power |
3.5kW |
5kW |
5.5kW |
5.5kW |
5.5kW |
5.5kW |
5.5kW |
|
Air Consumption |
200L/min |
200L/min |
200L/min |
300L/min |
300L/min |
300L/min |
300L/min |
